CyberServe Altra AA1 212-4NVMe®

Broadberry Ampere Altra Max ARM Server - 2U, 8x SATA, 4x NVMe, Dual Ethernet, 800W 1+1 Redundant

  • Supports up to 2 x double slot GPU cards
  • 8-Channel RDIMM/LRDIMM DDR4, 32 x DIMMs
  • Dual ROM Architecture supported
  • 2 x 1Gb/s LAN ports (Intel® I350-AM2)
  • 1 x Dedicated management port
  • 6 x 3.5"/2.5" Gen4 NVMe hot-swappable SSD bays in front side
  • 6 x 3.5"/2.5" SATA hot-swappable HDD/SSD bays in front side
  • 1 x Ultra-Fast M.2 with PCIe Gen4 x4 interface
  • 4 x full-height PCIe Gen4 x16 expansion slots
  • 4 x low profile PCIe Gen4 x8 expansion slots
  • 2 x OCP 3.0 Gen4 x16 mezzanine slots
  • 2000W 80 PLUS Platinum redundant power supply
  • Supports up to 6x SATA3 and SAS 2.5" Hard Drives
  • Configurable with 2x ARM Ampere Altra ARM
  • Supports up to 32 modules of DDR4 ECC Registered Memory
  • 6x PCI Express Expansion Slots
  • Configurable with up to 4.1TB Server Memory



Loading Configurator...

Prices for products are subject to change without notice and Prices do not include shipping and/or handling charges or applicable taxes.

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Trusted CyberServe Server Platform

The Broadberry range of CyberServe® rackmount are trusted as the server of choice for thousands of companies from SMBs to enterprise's across the globe.

Supports SATA Drives

This system can be configured with SATA drives for cost-effective 12gb/s storage.

Small Form Factor Storage

The CyberServe Altra AA1 212-4NVMe boasts high density storage and ultimate energy efficiency, catering for up to 6x High-Performance 2.5" SSD or Hard Drives


The CyberServe Altra AA1 212-4NVMe is a 2U rackmount server configurable with 2x Ampere Altra series range of processors. Built using the latest enterprise-class server technology, the CyberServe Altra AA1 212-4NVMe has 6x 2.5" SATA Hot-Swap Drives and is ideal for those requiring a combination of high performance and density with its 32x DDR4 ECC Registered memory banks providing up to 4.1TB of high-performance server memory. The CyberServe Altra AA1 212-4NVMe boasts as just a few of its core features.

The added benefit of hot-swap hard drives means that the CyberServe Altra AA1 212-4NVMe can have any of its 6 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted. The added benefit of hot-swap hard drives means that the CyberServe Altra AA1 212-4NVMe can have any of its 6 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted.

Storage Technology

The CyberServe Altra AA1 212-4NVMe supports 6x 2.5" desktop and enterprise-class SATA hard drives, which represents the best cost per GB ratio storage technology.

Originally designed and utilised in mobile applications such as laptops and notebooks, 2.5" hard drives are becoming ever increasingly used in servers due to their lower power consumption and space-saving characteristics. The added benefit of hot-swap hard drives means that the CyberServe Altra AA1 212-4NVMe can have any of its 6 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted.

Configure for your Network

The CyberServe Altra AA1 212-4NVMe’s ready to be deployed into your network environment with a wide-range of high-throughput connectivity options.

Configure the CyberServe Altra AA1 212-4NVMe to match your application I/O demands and network infrastructure with up to 6x Intel Gigabit Ethernet Adaptors , Intel 10 Gigabit Ethernet Adaptors, Intel 25/40/50 Gigabit Ethernet Adaptors, Intel 100 Gigabit Ethernet Adaptors, Mellanox ConnectX-4 Series Ethernet Adaptors, Mellanox Ethernet Adaptors, Broadcom Ethernet Adaptors.

Whether your application demands the highest networking throughput, or you’re looking for a more modest enterprise-grade networking option such as Gb/E, the CyberServe Altra AA1 212-4NVMe is totally customisable with a wide range of robust I/O connectivity options.

IPMI 2.0 & KVM over IP

Whereas most server manufacturers charge ongoing licence fees for IPMI, powerful, industry-standard server management is built in to the CyberServe Altra AA1 212-4NVMe at no extra cost.

Using the dedicated 3rd LAN port or on-board Gigabit Ethernet ports, you can take full control of the server as though you were standing in front of it through your web browser from anywhere in the world through a pre-defined IP address and password.

Check the health of the CyberServe Altra AA1 212-4NVMe components, fan speeds, temperatures, update firmware, check logs & set SMTP alerts for you pre-configure thresholds, and list the health of all your servers on one simple screen.

The CyberServe Altra AA1 212-4NVMe IPMI feature also allows complete Keyboard Video and Mouse (KVM) control, and send CD/DVD Images over IP to install software & operating systems remotely.

Expand with PCI-Express Expansion

Configure the CyberServe Altra AA1 212-4NVMe with up to 6x Intel Gigabit Ethernet Adaptors , Intel 10 Gigabit Ethernet Adaptors, Intel 25/40/50 Gigabit Ethernet Adaptors, Intel 100 Gigabit Ethernet Adaptors, Mellanox ConnectX-4 Series Ethernet Adaptors, Mellanox Ethernet Adaptors, Broadcom Ethernet Adaptors. With a wide range of enterprise-class PCI-Express add-on options available, the CyberServe Altra AA1 212-4NVMe is a flexible platform for a wide-range of applications.

The added benefit of hot-swap hard drives means that the CyberServe Altra AA1 212-4NVMe can have any of its 6 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted.
