Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP®

Configure a Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP

  • Virtualization
  • Cloud Computing
  • High End Enterprise Server
  • Dual socket P (LGA 3647) supports Intel Xeon Scalable Processors, Dual UPI up to 10.4GT/s
  • Up to 3TB ECC 3DS LRDIMM or RDIMM, up to DDR4-2666MHz; 24 DIMM slots
  • 2 PCI-E 3.0 x16 slots (FH, 10.5" L), 2 PCI-E 3.0 x8 slots (1 LP, 1 internal LP)
  • 2 10G SFP+ Ethernet ports
  • 4 Hot-swap 3.5" Drive Bays
  • 8 Heavy duty fans w/ optimal fan speed control
  • 750W Redundant Power Supplies Platinum Level (94%+)

Configure From $2,056.27  or  Buy Now




Loading Configurator...

Prices for products are subject to change without notice and Prices do not include shipping and/or handling charges or applicable taxes.

Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP Specifications

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon SP processor range, delivering massive improvements in every metric over the previous generation of Xeon E7 and E5 processors.

Up to 12 DIMMs per CPU

This system is capable of supporting up to 12 DIMMS per CPU. That’s a significant advancement on the previous limit, which was 9 DIMMS per CPU.

Security Without Compromise

Intel Xeon Scalable Processor based servers feature security without compromise, incorporating a number of technologies that aid in safeguarding your system.

Accelerated Applications

Applications can be accelerated via the addition of Intel QAT (Quick Assist Technology) to a software-defined infrastructure environment.

Configure With Dual Processors

Featuring dual processors, this system enjoys boosts to its performance for multi-threaded programs, allowing for smooth performance for the most demanding CPU intensive applications.

Configure With Up to 3TB of RAM

Equipable with up to a monstrous 3TB of RAM, allowing for super fast and ultra efficient multi-tasking for even the most demanding of applications.

Optimised For Cloud Computing

Optimised for cloud computing. Cloud computing provides a variety of advantages including better security, better TCO, 24 hour access and easy implementation.

Featuring Redundant Power Supply

Coming with a redundant power supply, this system has a backup power source it can fall back on if the original power source were to fail.

Configure With Hot-Swap Drives

The Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 3.5" Drives

Configure the Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP with 3.5" drives. These drives are more cost-effective, offer a larger storage capacity and offer more flexibility.


[[
Product SKUs
SYS-6019U-TRTP
  • SuperServer 6019U-TRTP (Black)
Motherboard

Super X11DPU
Processor/Cache
CPU
  • Dual Socket P (LGA 3647)
  • Intel Xeon Scalable Processors,
    Dual UPI up to 10.4GT/s
  • Support CPU TDP 70-205W
Cores
  • Up to 28 Cores with Intel HT Technology
System Memory
Memory Capacity
  • 24 DIMM slots
  • Up to 3TB ECC 3DS LRDIMM, 3TB ECC RDIMM, DDR4 up to 2666MHz
Memory Type
  • 2666/2400/2133MHz ECC DDR4 SDRAM
On-Board Devices
Chipset
  • Intel C621 chipset
SATA
  • SATA3 (6Gbps); RAID 0, 1, 5, 10
Network Connectivity
  • 2 10G SFP+ ports via AOC-URN2-I2XS (Intel 82599ES)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • ASPEED AST2500 BMC
Input / Output
SATA
  • 4 SATA3 (6Gbps) ports
LAN
  • 2 10G SFP+ ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 3 USB 3.0 ports (2 rear, 1 Type A)
Video
  • 2 VGA ports (1 rear, 1 onboard)
Serial Port
  • 1 Serial header
DOM
  • 2 SATA DOM (Disk on Module) support with embedded power
System BIOS
BIOS Type
  • AMI 32Mb SPI Flash ROM
Management
Software
  • Intel Node Manager
  • IPMI 2.0
  • KVM with dedicated LAN
  • NMI
  • SSM, SPM, SUM
  • SuperDoctor 5
Power Configurations
  • ACPI Power Management
PC Health Monitoring
CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-819UTQ-R751-T
Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 29" (737mm)
Weight
  • Net Weight: 26 lbs (11.8 kg)
  • Gross Weight: 41 lbs (18.6 kg)
Available Color
  • Black
Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • Network activity LEDs
  • System Overheat LED / Fan fail LED /
    UID LED
Expansion Slots
PCI-Express
  • 2 PCI-E 3.0 x16 (Full-height, 10.5" L)
  • 2 PCI-E 3.0 x8 (1 LP, 1 internal LP)


  • (Both CPUs need to be installed for full access to PCI-E slots and onboard controllers. See manual block diagram and AOC Support for details.)
Drive Bays
Hot-swap
  • 4 Hot-swap 3.5" drive bays
  • 4 SATA3 (optional SAS3 via AOC)
System Cooling
Fans
  • 8 Heavy duty fans with optimal fan speed control
Air Shroud
  • 1 Air Shroud
Power Supply
750W Redundant AC-DC Power Supplies, +12V/+12Vsb output
AC Input
  • 100-127Vac, 50-60Hz
  • 200-240Vac, 50-60Hz
+12V
  • Max: 62.5A & Min: 0A (100Vac-127Vac)
  • Max: 62.5A & Min: 0A (200Vac-240Vac)
12V SB
  • Max: 2.1A
  • Min: 0A
Certification Platinum Level

Operating Environment
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
    10C ~ 35C (50F ~ 95F)
  • Non-operating Temperature:
    -40C to 60C (-40F to 140F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)

]]

A 1U Supermicro SuperServer based on 2x Intel Xeon Scalable Processors range of processors, the Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP is configurable with up to 4x Hot-Swap Drives drive bays, and designed for optimal performance with 24x DDR4 memory sockets .

The Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP supports the Intel Xeon Scalable Processors family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP boasts 4 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: Intel Xeon Scalable Processors
  • Range: Cloud Computing Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 3.5" Drives
  • Maximum RAM Capacity: 3.1TB

Broadberry Price Guarantee

We're so confident in our great value solutions, If you find a cheaper genuine price for the same specifications elsewhere we'll match it.


How to order

You can order by either calling us and speaking to one of our experienced US technical sales team, or pressing "Email Quote".

Supermicro SuperServer 6019U-TR4 | SYS-6019U-TR4 Supermicro SuperServer 6019U-TRTP | SYS-6019U-TRTP Supermicro SuperServer 6019U-TR25M | SYS-6019U-TR25M Supermicro SuperServer 6019U-TRT | SYS-6019U-TRT Supermicro SuperServer 6019U-TRTP2 | SYS-6019U-TRTP2 Supermicro SuperServer 6019U-TR4T | SYS-6019U-TR4T Supermicro SuperServer 6019U-TN4RT | SYS-6019U-TN4RT Supermicro SuperServer 6019U-TN4R4T | SYS-6019U-TN4R4T
Configure From: $1,928
Configure
Configuring From: $2,056
Configure From: $2,056
Configure
Configure From: $2,062
Configure
Configure From: $2,075
Configure
Configure From: $2,169
Configure
Configure From: $2,304
Configure
Configure From: $2,431
Configure
ChassisSYS-6019U-TR4SYS-6019U-TRTPSYS-6019U-TR25MSYS-6019U-TRTSYS-6019U-TRTP2SYS-6019U-TR4TSYS-6019U-TN4RTSYS-6019U-TN4R4T
U Size1U1U1U1U1U1U1U1U
Processor FamilyIntel Xeon Scalable ProcessorsIntel Xeon Scalable ProcessorsIntel Xeon Scalable ProcessorsIntel Xeon Scalable ProcessorsIntel Xeon Scalable ProcessorsIntel Xeon Scalable ProcessorsIntel Xeon Scalable ProcessorsIntel Xeon Scalable Processors
High-Density Twin Servers
Drive BaysHot-Swap DrivesHot-Swap DrivesHot-Swap DrivesHot-Swap DrivesHot-Swap DrivesHot-Swap DrivesHot-Swap DrivesHot-Swap Drives
HDD Size3.5" Drives3.5" Drives3.5" Drives3.5" Drives3.5" Drives3.5" Drives3.5" Drives3.5" Drives
Integrated FeaturesDual 10GbE Lan with SFP+Dual 25GbE SFP28Dual 10GBase-T Ports Dual 10G SFP+ and Dual 1GbEQuad 10GBase-T PortsDual 10GBase-T Ports Quad 10GBase-T Ports
CPU SocketsDual ProcessorDual ProcessorDual ProcessorDual ProcessorDual ProcessorDual ProcessorDual ProcessorDual Processor
